SC/APC To SC/APC Single Mode Fiber Patch Cable Simplex LSZH 3m 2.0mm Patch Cord

Place of Origin : Made in China

Brand Name : GoreLink

Certification : ISO,RoHS,REACH

MOQ : 1 Piece

Packaging Details : Neutral Bag/GoreLink Bag

Delivery Time : 1-3 Working days

Payment Terms : T/T,Paypal,Western Union

Model Number : G218-1441-3

Product : Fiber Optic Patch Cord

Part Number : G218-1441-3

Application : FTTH FTTB FTTX Fiber Optic Networks

Connector : SC/APC-SC/APC

Polish : APC

Fiber Mode : Singlemode G652D

Cable Type : Simplex

Cable Diameter : 2.0mm

Jacket : LSZH

Length : 3m

Insertion Loss : ≤0.3dB

Return Loss : ≥55dB

Wavelength : 1310nm, 1550nm

Operating Temperature : -20℃ to 70℃

Contact Now



Fiber Optic Patch Cord, SC/APC-SC/APC Singlemode Simplex,LSZH,3m,2.0mm

Fiber optic patch cord, also known as fiber optic patch cables or jumpers, are essential components in fiber optic networks. Gorelink Singlemode 9/125um OS2 Fiber Optic Patch cord is ideal for supporting high-speed network connection.It has an LSZH(Low Smoke Zero Halogen) jacket, which protects from toxic and corrosive gases in poorly ventilated spaces and other areas where it is most critical. This cable also provides backward compatibility with existing 9/125 equipment and the performance headroom required to support LED and VCSEL laser light sources.


Application


  • FTTH access network

  • Telecommunication Networks

  • CCTV Networks

  • Data Center

  • Local Area Networks


General Specification



   Fiber Mode

  Singlemode 9/125um OS2

   Cable structure

  Simplex

   Connector A

  SC

   Connector B

  SC

   Polishing

  APC-APC

   Strength Member

  Aramid Yarn

   Cable Diameter

  2.0mm

   Cable Color

  Yellow

   Connector Color

  APC

  Green (SC,LC)

Black (ST,FC)

   Cable Jacket

  LSZH

   Cable length

  As per the order request

   OPTICAL PERFORMANCE

   Attenuation

  ≤3.5dB/KM

   Fiber Type

  G.652D

  G.657A1/A2

   Insertion Loss(IL)

  ≤0.3dB(UPC)

  ≤0.3dB(UPC)

   Return Loss(RL)

  ≥50dB(UPC)

  ≥50dB(UPC)

   Operating Temperature

  -10 to + 70℃

   Storage Temperature

  -10 to + 80℃




SC/APC To SC/APC Single Mode Fiber Patch Cable Simplex LSZH 3m 2.0mm Patch Cord  SC/APC To SC/APC Single Mode Fiber Patch Cable Simplex LSZH 3m 2.0mm Patch Cord







Ordering Information



PART NO.

DESCRIPTION

G218-1441-1

Fiber optic patch cord, SC/APC-SC/APC SM Simplex 2.0mm LSZH jacket 1m

G218-1441-2

Fiber optic patch cord, SC/APC-SC/APC SM Simplex 2.0mm LSZH jacket 2m

G218-1441-3

Fiber optic patch cord, SC/APC-SC/APC SM Simplex 2.0mm LSZH jacket 3m

G218-1441-5

Fiber optic patch cord, SC/APC-SC/APC SM Simplex 2.0mm LSZH jacket 5m

G218-1441-10

Fiber optic patch cord, SC/APC-SC/APC SM Simplex 2.0mm LSZH jacket 10m

G218-1441-15

Fiber optic patch cord, SC/APC-SC/APC SM Simplex 2.0mm LSZH jacket 15m

G218-1441-20

Fiber optic patch cord, SC/APC-SC/APC SM Simplex 2.0mm LSZH jacket 20m

*  Customized


If you need any further assistance, please feel free to contact us at sales@gorelink.com .
