Fiber Optic LC APC Patch Cord Singlemode G652D Duplex LSZH 3m 2.0mm

  • 1
  • 2

Place of Origin : China

Brand Name : GoreLink

Certification : ISO,RoHS,REACH

MOQ : 1 Piece

Packaging Details : Neutral Bag/GoreLink Bag

Delivery Time : 1-3 Working days

Payment Terms : T/T,Paypal,Western Union

Model Number : G218-1222-3

Product : Fiber Optic Patch Cord

Features : Low insertion loss and high return loss

Application : FTTH FTTB FTTX Network

Part Number : G218-1222-3

Connector Type : LC/APC-LC/APC

Fiber Mode : Singlemode

Type : Duplex

Jacket Material : LSZH

Length : 3m

Cable Diameter : 2.0mm

Insertion loss : ≤0.3dB

Return loss : ≥55dB

Wavelength : 1310nm,1550nm

Contact Now

Fiber Optic Patch Cord, LC/APC-LC/APC Singlemode Duplex,LSZH,2.0mm


Gorelink Singlemode 9/125um OS2 Fiber Optic Patch cord is ideal for supporting high-speed network connections.It has a LSZH(Low Smoke Zero Halogen) jacke, which protects from toxic and corrosive gases in poorly ventilated spaces and other areas where it is most critical. This cable also provides backward compatibility with existing 9/125 equipment and the performance headroom required to support LED and VCSEL laser light sources.


Application


  • FTTH access network

  • Telecommunication Networks

  • CCTV Networks

  • Data Center

  • Local Area Networks


General Specification




   Fiber Mode

  Singlemode 9/125um OS2

   Cable structure

  Duplex

   Connector A

  LC

   Connector B

  LC

   Polishing

  APC-APC

   Strength Member

  Aramid Yarn

   Cable Diameter

  2.0mm

   Cable Color

  Yellow

 Connector Color

  UPC

Blue

APC

Green

   Boot Color

White

Green

   Cable Jacket

  LSZH

   Cable length

  As per the order request

   OPTICAL PERFORMANCE

   Attenuation

  ≤3.5dB/KM

   Fiber Type

  G.652D

G.657A1/A2

   Insertion Loss(IL)

  ≤0.3dB(UPC)

 ≤0.3dB(UPC)

≤0.3dB(APC)

   Return Loss(RL)

  ≥50dB(UPC)

≥50dB(UPC)

≥60dB(APC)

   Operating Temperature

  -10 to + 70℃

   Storage Temperature

  -10 to + 80℃







Fiber Optic LC APC Patch Cord Singlemode G652D Duplex LSZH 3m 2.0mmFiber Optic LC APC Patch Cord Singlemode G652D Duplex LSZH 3m 2.0mm






Ordering Information



PART NO.

DESCRIPTION

G218-1222-1

Fiber optic patch cord, LC/APC-LC/APC SM Duplex 2.0mm LSZH jacket 1m

G218-1222-2

Fiber optic patch cord, LC/APC-LC/APC SM Duplex 2.0mm LSZH jacket 2m

G218-1222-3

Fiber optic patch cord, LC/APC-LC/APC SM Duplex 2.0mm LSZH jacket 3m

G218-1222-5

Fiber optic patch cord, LC/APC-LC/APC SM Duplex 2.0mm LSZH jacket 5m

G218-1222-10

Fiber optic patch cord, LC/APC-LC/APC SM Duplex 2.0mm LSZH jacket 10m

G218-1222-15

Fiber optic patch cord, LC/APC-LC/APC SM Duplex 2.0mm LSZH jacket 15m

G218-1222-20

Fiber optic patch cord, LC/APC-LC/APC SM Duplex 2.0mm LSZH jacket 20m

*  Customized


If you need any further assistance, please feel free to contact us at sales@gorelink.com .
